VL-LRD Series

Low Angle Ring Diffused Light

VAL
  • Design: Compact design.
  • Light: evenly spread out onto the object surface
  • Prevention: of LED glare and reflections.
  • Suitable: for inspection of glossy object.
VL-LRD Series
Codice variante Color External Ring dia. (mm) Internal Ring dia. (mm). Power Consumption (Max.) Pdf Spec
VL-LRD2040W-1 White 40 20 24V / 5.3W
VL-LRD2075R Red 75 20 24V / 4.4W
VL-LRD2075W White 75 20 24V / 8.8W
VL-LRD2075B Blue 75 20 24V / 8.0W
VL-LRD2075IR850 IR850 75 20 24V / 11.5W
VL-LRD4577R Red 77 45 24V / 3.5W
VL-LRD4577W White 77 45 24V / 9.2W
VL-LRD4577B Blue 77 45 24V / 8.4W
VL-LRD4577G Green 77 45 24V / 8.6W
VL-LRD73100R Red 100 73 24V / 3.2W
VL-LRD73100W White 100 73 24V / 6.4W
VL-LRD73100B Blue 100 73 24V / 6.1W
VL-LRD153180R Red 180 153 24V / 4.5W
VL-LRD153180W White 180 153 24V / 11.4W
VL-LRD153180B Blue 180 153 24V / 11.4W
